2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector

I'm Online Chat Now

2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector

China 2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector supplier
2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector supplier 2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector supplier

Large Image :  2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector

Product Details:

SGS ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: 10pcs in blister bag
Delivery Time: 2days for samples, 7-15days for bulk order
Payment Terms: L/C, T/T, Western Union, Payapl
Supply Ability: 10000pcs/day
Contact Now
Detailed Product Description
Model Number: SCUPC Insert Loss: Max<=0.5dB ,Average<=0.3dB
Return Loss: >= -40dB Cable Type: 2 X3mm .2.0mm ,0.9 Mm Cables
Connector Length: 60mm Connector Structure: Pre -embeded Type
Fiber Type: SM Or MM Connector Color: Blue

2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector



The Fast Connector also is called "Field Assembly Connector" or "Field terminated fiber connector" or "quickly assembly Fiber connector". It is designed for simple and fast field termination of single fibers, without polishing or epoxy. The unique design is a pre-polished ferrule and a mechanical splice inside the connector body.
Assembly of the SC type quick connector requires only normal fiber preparation tools: a fiber stripping tool, wipes and a fiber cleaver. No electrical power supply is needed.
Our Fast Connector series connectors are now available in FC, SC and LC variants, catering for 250um to 900um diameter single mode and multimode fiber types, including Multi-mode 62.5/125um and Multi-mode 50/125um. The single-mode versions are available with PC or APC ferrules.

2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector





1.  Features:



This Fast Connectors feature a pre-stubbed factory-polished ferrule that couples to the fiber being terminated. Precision mechanical alignment insures low loss with a proprietary gel.
Connector Type: SC
Fiber Application: Singlemode, Multimode
Fiber Type: Simplex
Number of Fibers: 1
Maximum Cable Diameter (mm):  900um, 2mm, 3mm or 2X3mm Fiber Types
Connector Ferrule: Ceramic


2. Specifications:



Parameter
Item Parameter
Single-Mode Multi-Mode
Insertion Loss Max<=0.5dB ,Average<=0.3dB
Return Loss >=40dB
Durability (1000 Mating) 0.2dB Max.
Operating Temperature -40°C~+75°C
Storage Temperature -40°C~+85°C
Remark: Ferrule Concentricity SM< 1um; MM< 1.4um Ferrule inner diameter tolerance +1/-0um Ferrule outer diameter tolerance +/-0.5 um



2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector

2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector

4. Packing



2 X 3 mm Cables Field Assembly Connector , SM / MM LC Fiber Optic Connector





5. Nia Fiber Service:



Niafiber Africa Ltd



We not only have top-ranking quality control departments but also establish complete and reliable quality assurance system. We carry out the system in all procedures and processes of production and management. Moreover, we adopt advanced quality control equipment and first-rate expert team, making sure best products' quality to customers in the whole world.
