Duplex MM LC-FC Fiber Optic Patch Cord Optical Cable LSZH FTTH Patch Cord
Features
- Low insertion loss and hight return loss
- Excellent repeatability and changeability
- Simplex and duplex available
- With ceramic fettules
- PVC&LSNH cable option
- Optical performance 100% factory test
Application
-
Local Area Networks (LANs) and Wide Area Networks (WANs)
-
Fiber Optic CATV, FTTH, FTTB, FTTP etc
-
Fiber Optic telecommunication systems
-
Transmission Mode (ATM)
-
Fiber Optic Backbone
-
Military Instrumentatio
Specifications
| Fiber Type |
SM |
MM |
| Normal Fiber OD |
125±0.2um |
125±0.2um |
| Connector Type |
SC,FC,ST, E-2000, LC, MU |
MTRJ |
SC,FC,ST, E-2000, LC, MU |
MTRJ |
| Insertion loss(Typical) |
0.2dB |
0.4dB |
0.2dB |
0.4dB |
| Insertion loss(Max) |
0.3dB |
0.5dB |
0.3dB |
0.5dB |
| Return Loss(Typical) |
PC |
50dB |
35 |
- |
| UPC |
55dB |
- |
- |
| APC |
65dB |
- |
- |
| Mating Durability(500 C) |
0.2dB |
| Temperature Stability |
0.3dB |
| Operation Temperature |
-25°C~+70°C |
| Storage Temperature |
-25°C~+70°C
|
Order Information
| Item |
Type |
| Fiber optic connector |
LC,FC,SC,ST,MTRJ,JU,DIN,D4,MPO,SMA,E2000 |
| Polishing |
PC,UPC,APC |
| Fiber optic cable model |
Singlemode: g652d, g655, g657a |
| Multimode: 62.5/125(OM1), 50/125(OM2), OM3, OM4 |
| Fiber optical cable diameter |
0.6mm, 0.9mm, 1.6mm, 2.0mm, 2.4mm, 3.0mm |
| Fiber brand |
Corning, YOFC |
| Fiber Cores |
simplex, duplex, multicore (4-48cores) |
| Fiber optic patch cord length |
0.5m to 1km are available |
| Fiber optic cable type |
Indoor, ribbon, bunch, armored, waterproof, outdoor
|
Our Service
Nia Fiber specializes in manufacturering of FTTH products and fiber optic cables. Nia Fiber provides connectivity solutions for some of the largest distributors and OEM accounts in the world. We provide both standard and custom solutions for our customer's specific requirements.
Total Quality is the guiding principle of Nia Fiber's business life. It requires each of us, individually and in teams, to understand, anticipate, and surpass the expectations of our customers. Total Quality demands continuous improvement in all our processes, products, and services. Our success depends on our ability to learn from experience, to embrace change, and to achieve the full involvement of all our employees. The company's expertise assures that each customer will receive the highest quality of products and service on each and every product. By purchasing Nia Fiber products, our customers can be assured that they are getting components that are fully warranted.
All products can be custom manufactured to fit customer requirements.If you need something special, Nia Fiber can design and manufacture a custom fiber optic cable or cable assembly to meet your requirements.
FAQ:
Q1: Are you a factory?
A: Yes, we are a factory, we have 6 workshops, patch cord, hardware, injection moulding, painting, die making work shop.
Q2: what's your products' quality control?
A: Our tenet is "Quality first, Prestige first".
1.Control the raw material,manpower allocation,working environments,equipment etc.
2.Improve the working standard ,cooperation ,training of workers etc.
3.The supporting of boss on quality control.
4.Our products have passed the CE & ROHS & ISO etc.
Q3: Do you offer guarantee for the products?
A: Yes, we offer 1-2 years warranty to our products.
Q4. Q: Could you offer the OEM service?
A: Yes, we can provide both OEM and ODM service, manufacture as per your request.
Q5. May I take a sample order
A: Yes, Professional manufacturer, 100% tested, samples are available.
Q6. What about the lead time?
A:Sample takes 3 days, mass production time takes 7-15 days for bulk order.
Q7. What about the shippment and how long does it take to arrive?
A: Goods usually be shipped by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q8. Ordering guide as follow :
Firstly, let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly, customer confirms the samples and places deposit for formal order.
Fourthly, We arrange the production.
