Specifications
1.SC,LC,FC,ST,MU,MTRJ,D4,DIP,E2000
2.0.9mm / 2.0mm / 3.0mm
3.SM/MM SX/DX
4.100% optically
Technical specifications:
Connectors are built under test of industrial standard, meet TIA/EIA-568-8.3
AND iso/iec 11801:202 Ed2.0, Telcordia (Belicore) GR-326-Core. Singlemode fiber connectors and patch cord requirement.
IEC874-1 fiber connector and cable instruction, based on TIA/EIA-568 standard on A-8 designing, 568SC ZIP patch cords are internal cross-over, A-B to B-A, suitable for MTRJ-MTRJ and LC-LC and hybird patch cord. (568SC-ST, 569SC-MTJ and MTRJ-ST compatible duplex patch cord). All patch cords are label with printing on the cable.
| Pigtail Connector |
PC (SM) |
UPC (SM) |
APC (SM) |
MM |
| Return Loss (dB) |
≥45 |
≥50 |
≥60 |
≥35 |
| Insertion Loss (dB) |
≤0.2 (max≤0.3) |
| Repeatability (dB) |
≤0.1 |
| Durability(1/Matings) |
≥500 |
| Operation Temperature (°C) |
-25~+70 |
| Tensile Strength (N) |
≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9 |
| Fiber |
9/125um, 50/125um,62.5/125um,ect |
| diameter |
0.9mm 2.0mm, 3.0mm etc |
| Cable material |
PVC, LSZH |
| Cores |
Simplex, duplex, 4cores, 6cores, 8cores, 12cores etc |
Features:
---Good durability
---Good exchangeability
---High temperature stability
---Low insertion loss and back reflection loss
---Superior Quality Standard PC/UPC/APC Polishing
---Standard: Telcordia GR-326-CORE, TIA/EIA and IEC
Applications:
Gigabit Ethernet; Active device termination; Telecommunication networks; Video;
Multimedia; Premise installations; Local area networks; FTTH FTTX applications; CATV.
Our Services:
Nia Fiber views business from the customer’s perspective, sensitive to the pressures of a production environment. A good supplier is one you can depend on for quality, technical support, reliability, and fast delivery of components when you need them. We do our job so you can do yours. Quality is cost effective. Re-makes, delays and failures are expensive. Nia Fiber stocks a range of quality components to anticipate the changing needs, as well as potentialproblems, that the customer (and other vendors) might overlook. We offer support and technical expertise in both the newest and existing technologies. Our aim is to make the business part easy.
Nia Fiber works hard to be part of your success. We do business only with suppliers committed to supporting their products and the fiber professionals who use them, and we have long term relationships with these suppliers.
FAQ:
Q1. How to shipping ? Is there cheap shipping cost to import to our country ?
A1 : The best choice is shipping By Sea . Because network cable is very heavy , it's too expensive by air .
By Sea : If you have freight forwarder , they can handle shipping for you . If you don't have it , we can provide the cheapest shipping cost to you .Or send our freight forwarder informaitons to you contact directly .
By Air : You can try to contact with DHL,Fedex,UPS express etc. after got weight and CBM from us . But it's more cheaper by China express agent ,you can contact with our sales to get the cheapest freight cost .
Q2. How to know recycle and new jacket materials ?
A2 : Except for conductor price , the jacket materials is the main factors affecting price . Some supplier price is crazy , because they use recycle materials in production . How to make out ?
Recycle material : The jacket will have bubble , especially tenacity is very bad , it's easy to tear . So the cable lifetime is short , and fire retardant, cold resistance is very bad .
New material : Tenacity is very good , it's hard to tear . And with good fire retardant, cold resistance .
Q3. Can you make OEM ? What about packing box ?
A3 : Definitely , our main business is make OEM order .
Cable Marking/Printing : It can be marking your brand or any printing that you want , except for international famous brand .
PE bag packing designs : If you want make your own brand PE bag designs, you must meet Box factory MOQ 20000 pcs at least, and the new mould charges will depend on the designs.
Outer Carton : We will support you free to make your own brand carton.
If you have box designs, just send it to us . If not , we have professional designers to make becautiful custom-made box designs for you.
Q4. What about the after-sales sevice ?
A4 : Our cable will provide free change for new if there is any quality problem in your order.
