1core/2 core,/4core,/6core/8core/10core/12core FTTH cable with FRP strength member GYXFTPY optical fiber for telecommuni
The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. A Fiber Reinforced Plastic (FRP) locates in the center of core as a non-metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular core. After the cable core is filled with the filling compound to protect it from water ingress, the cable is completed with a PE sheath.
1. Products feture:
Good mechanical and temperature performance;
High strength looes tube that is hydrolysis resistant;
Special tube filling compound ensure a critical protection of fiber;
Crush resistance and flexibility;
Inexpensive and can reduce operating costs;
Two parallel steel wires ensure tensile strength;
Small diameter, light weight and friendly installation;
Long delivery length;
2. Specification:
| Model Number |
GYXTPY |
| Type |
Coaxial |
| Number of Conductors |
2 |
| Certification |
UL ,ROHS,SGS |
| Fiber |
SM/MM/OM3/OM4 |
| Fiber Core |
1~12 core |
| Jacket Material |
PE /LSZH/PU |
| Laying method |
Pipeline/Overhead |
| keywords |
outdoor fiber optic cable |
| Color |
Black or customized |
| Fiber brand |
Corning, LS, etc |
| Fire Resistant |
Yes |
| Application |
FTTH |
Optical Characteristics:
| |
G.652D |
50/125μm |
62.5/125μm |
| Attenuation (+20℃) |
@850nm |
|
≤3.0 dB/km |
≤3.0 dB/km |
| @1300nm |
|
≤1.0 dB/km |
≤1.0 dB/km |
| @1310nm |
≤0.36 dB/km |
|
|
| @1550nm |
≤0.22 dB/km |
|
|
| Bandwidth (Class A) |
@850nm |
|
≥500 MHz·km |
≥200 MHz·km |
| @1300nm |
|
≥1000 MHz·km |
≥600 MHz·km |
| Numerical Aperture |
|
0.200±0.015NA |
0.275±0.015NA |
| Cable Cut-off Wavelength λcc |
≤1260nm |
|
|
Standards:
GYXTPY cable complies with Standard YD/T 769-2003.
Storage/Operating Temperature: -40°C to + 70°C
